Elbow

Pipe elbow fittings is a very important pipe fitting. When we talk about a pipe elbow, it means a length of pipe with a sharp bend in it. Pipe elbows are fitting accessories which are used widely in various industrial sectors in pipe fitting. A pipe elbow is frequently used in pressurized applications and are available in various shapes and sizes for use in different applications. A pipe elbow is a fitting installed between two lengths of pipe or tube allowing a change of direction, usually in the 90° or 45° direction.

Size:

OD: 1/2"-24" seamless, 26"-60" welded

WT: SCH5S,10S,10,40S,STD,XS,80S,XXS,40,60,80,160,XXS

30° 45° 60° 90° 180°,etc

LR/long radius=1.5D,SR/Shrot radius=1D, various radius: 3D,4D,5D,6D,7D

Pipe Standard:

ANSI B16.9, EN10253-4, DIN 2605, GOST 17375, JIS B2313, MSS SP 75

Stainless Steel A403 WP 304/L,316/L,321,310S,347H,317,316Ti,904L

ASTM A234 WP1/5/9/11/12/22/91

Duplex stainless steel: UNS31803, SAF2205, UNS32205, UNS31500
